CYLINDER BLOCK/CRANKCASE
Page 4B-37
90-828631R3 MARCH 1999
CRANKSHAFT WITHOUT NUT
11
3
4-Stroke Outboard Oil (92-828000A12)
11
3
a
c
d
e
f
b
g
g
NOTE:
Load Ring is for one time use and must be replaced if flywheel is removed.
a-
W
asher
, Lower
b-
Woodruff Key
c-
Drive Gear
d-
W
asher
, Upper
e-
Load Ring
f-
Spacer
g-
Insert Projections (3) on the Drive Gear into washer holes
Installing Powerhead Components
1.
Reinstall cylinder head. Refer to Section 4 Part A.
53740
277
279
