IGNITION
90-828631R3 MARCH 1999
Page 2A-21
FL
YWHEEL WITH LOAD RING & SP
ACER
53278
11
0
a
c
b
d
e
11
0
4-Stroke Outboard Oil (92-828000A12)
a-
Flywheel Key
b-
W
asher
c-
Nut
d-
Spacer
e-
Load Ring
NOTE:
Load Ring is for one time use and must be replaced if flywheel is removed.
Flywheel Nut T
orque
1
16 lb-ft (157 Nm)
81
83
