3
A
FUEL PUMP
90-828631R3 MARCH 1999 Page 3A-1
FUEL SYSTEM
Section 3A - Fuel Pump
Table of Contents
Specifications 3A-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel Pump 3A-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel Pump Operation 3A-4. . . . . . . . . . . . . . . . . . . . . .
Fuel Pump Removal 3A-5. . . . . . . . . . . . . . . . . . . . . . .
Fuel Pump Disassembly 3A-6. . . . . . . . . . . . . . . . . . .
Cleaning/Inspection/Repair 3A-7. . . . . . . . . . . . . . . . .
Fuel Pump Reassembly 3A-8. . . . . . . . . . . . . . . . . . . .
Fuel Pump Installation 3A-10. . . . . . . . . . . . . . . . . . . .
Specifications
FUEL SYSTEM
Fuel Pump Type
Fuel Pump:
Pressure
Diaphragm Stroke
Plunger Stroke
Fuel Tank Capacity
External (Plunger/Diaphragm)
3-6 psi
0.14 - 0.20 in. (3.5 - 5.1 mm)
0.23 - 0.38 in. (5.85 - 9.65 mm)
Accessory
