IGNITION
90-828631R3 MARCH 1999 Page 2A-5
Flywheel
TORQUE
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
1 1 COVER
2 2 GROMMET
3 1 TUBING (19 IN.)
4 2 DAMPER
5 1 NUT 116 157
6 1 WASHER
7 1 FLYWHEEL
8 1 DECAL-Warning Spinning flywheel
9 3 SCREW (M6 x 25) 75 8.5
10 1 STATOR
11 1 BASE–Stator
12 2 SCREW 100 11.5
13 2 PIN
14 1 KEY
15 1 COIL–Pulser
16 2 SCREW (M5 x 10) 45 5.0
17 1 DECAL-Warning Neutral
18 1 DECAL-Engine Oil/Valve clearance
19 1 DECAL-EPA INFO (1999)(SEE NOTE)
NOTE: THE EPA LABEL HAS IMPORTANT INFORMATION ON EPA EMISSION REGULATIONS. REPLACE ANY
MISSING OR UNREADABLE EPA LABEL.
To Next Page
