OUTBOARD MOTOR INST
ALLA
TION
90-828631R3 MARCH 1999
Page 1D-7
Wiring Harness
IMPORT
ANT
: W
arning Horn Requirement – The remote control or key switch assem-
bly must be wired with a warning horn. This warning horn is used with the engine
warning system.
1.
Route wiring harness into bottom cowl.
2.
Connect wiring. Place harness into the holder
.
GRN/WHT
BLU/WHT
BRN/WHT
TA
N
BLU/WHT
GRN/WHT
a
b
a-
Power T
rim Connections
b-
Holder – Place Harness Into Holder
53
