3A-2 - FUEL SYSTEM 90-830234R3 DECEMBER 1997
65 Jet 75-90 (3 cyl.)
51549
a
b
c
e
f
h
d
g
a - Body (Opposite Side View)
b - Rubber Valve
c - Plastic Disc
d - Cover (Opposite Side View)
e - Plastic Check Valve Retainer
f - Cast Aluminum Cover
g - Three Tabs
h - Three Tabs
