90-830234R3 DECEMBER 1997 FUEL SYSTEM - 3C-7
3 and 4 Cylinder Oil Flow Diagram
54129
a
b
c
d
e
f
g
h
i
j
k
l
m
a - Oil Tank Vent
b - Oil Tank
c - Low Oil/Overheat Warning Module
d - Fuel Enrichment Valve Fuel Fitting
e - Accelerator Pump Fitting (4 Cylinder Models Only)
f - Fuel Filter
g - To Crankcase Pulse Fitting
h - Fuel Pump
i - 2 psi (13.7kPa) Check Valve
j - Oil Pump Bleed Valve
k - Oil Pump
l - Fuel Inlet Fitting
m- Low Oil Sensor
