90-830234R3
DECEMBER 1997
LOWER UNIT - 6B-15
6.
Remove 5 bolts securing pump drive to drive
shaft housing and remove pump.
a
a
b
54165
a
-
Bolts (4)
b
-
Bolt (1)
Bearing Carrier Removal
NOTE:
Water pump assembly must be removed be-
fore bearing carrier can be removed.
1.
Remove 4 bolts (2 each side) securing water
pump assembly and remove water pump.
a
b
c
d
e
f
g
h
i
a
54166
a
-
Bolts (2 each side)
b
-
Seal
c
-
Housing
d
-
Impeller
e
-
Key
f
-
Gasket
g
-
Plate
h
-
Gasket
i
-
Spacer
504
506
