Mercury 90 Service Manual

90-830234R3 DECEMBER 1997 MID-SECTION - 5C-3
Power Trim Components (Yellow Fill Plug)
(S/N-USA-0G360003/BEL.-9934137 & UP)
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
– 1 POWER TRIM PUMP
1 1 SHOCK ROD KIT
2 1 O RING REBUILD KIT
3 1 MEMORY PISTON ASSEMBLY
4 1 CYLINDER ASSEMBLY
5 1 TRIM LIMIT VALVE KIT
6 1 PUMP ASSEMBLY
7 1 MOTOR KIT
8 1 RESERVOIR PLUG
9 1 MANUAL RELEASE ASSEMBLY
10 1 MANIFOLD KIT 100 11.3
11 1 SCREW KIT(MOTOR) 80 9.0
12 1 DRIVE SHAFT
13 1 FILTER KIT
14 1 P.O. CHECK ASSEMBLY KIT
– 1 O RING KIT(COMPLETE TRIM)
15 2 GROOVE PIN
16 1 ANCHOR PIN
17 1 SHAFT
18 2 SCREW(M6 x 25)(USA-0G437999/BEL-9926999 & BELOW) 35 4.0
19 2 RELAY
20 2 BUSHING
21 2 GROMMET
22 2 BRACKET
23 1 HARNESS ASSEMBLY (USA-0G437999/BEL-9926999 & BELOW)
24 1 HARNESS ASSEMBLY USA-0G438000/BEL-9927000 & UP
25 2
SCREW(M6 x 25) 35 4.0
26 2 CLAMP
27 2 SCREW(10-16 x 3/8) Drive Tight
28 2 C WASHER
29 1 TRIM HARNESS ASSEMBLY (Use where applicable)
