4-74 - POWERHEAD
90-830234R3
DECEMBER 1997
T
emperature Sensor Installation
3 Cylinder Models
b
a
a
-
T
emperature Sensor
b
-
Retainer Screws
4 Cylinder Models
a
b
53993
a
-
T
emperature Sensor
b
-
Retainer Screws
Carburetor Installation
•
Install carburetor gaskets.
•
Reinstall carburetors as a single unit assembly
.
Note manifold hose position and connection.
3 Cylinder Models
a
19094
a
-
Manifold Hose
a
4 Cylinder Models
25914
a
-
Base Gaskets
