90-830234R3 DECEMBER 1997 ELECTRICAL - 2A-17
* Connect test lead to BLACK stator lead if stator is
removed from engine.
4 CYLINDER WITH 16 AMPERE STATOR
398-9710A33
USA-0G301751 – 0G404616
BELGIUM - 09885528 – 09916721
Test Leads
Resistance
(OHMS)
Scale Reading
(x__________)
Between Blue Stator Lead
and Blue/Wht Stator Lead
(Low Speed)
1000-1400
1.0-1.4
(R x 1000)
Between Red Stator Lead
and Red/White Stator Lead
(Hi-Speed)
15-30
15-30
(R x 1)
NOTE: Above readings are for a cold engine (room
temperature). Resistance will increase slightly, if en-
gine is warm.
3. If meter readings are other than specified, re-
place stator assembly.
IGNITION COIL TEST
IMPORTANT: Ohmmeter tests can only detect
certain faults in the ignition coil. Replace ignition
coil, if ohmmeter readings (listed in chart, follow-
ing) are not as specified. If coil tests OK, and coil
is still suspected of being faulty, use Multi-Meter/
DVA Tester (91-99750) or a voltmeter (capable of
measuring 400 volts DC, or higher) and Direct
Voltage Adaptor (91-89045) to thoroughly check
coil.
1. Disconnect wires from coil terminals.
2. Pull spark plug lead out of coil tower.
3. Use an ohmmeter and perform the following
tests.
Test Leads
Resistance
(OHMS)
Scale Reading
(x__________)
Between (+) and
(–) Coil Terminals
.02-.04*
.02-.04*
(R x 1)
Between Coil Tower and
(–) Coil Terminal
800-1100**
8-11**
(R x 100)
* The primary DC resistance of these coils generally is less
than one (1) OHM. If a reading resembling a short is
obtained, this would be acceptable.
** Copper wire is an excellent conductor, but it will have a
noticeable difference in resistance from cold to hot
temperatures. Reasonable variations from these readings
are acceptable.
4. If meter readings are not as specified, replace
ignition coil.
TRIGGER TEST
1. Disconnect all trigger leads from switch box.
2. Use an Ohmmeter and perform the following
tests.
3 CYLINDER TRIGGER SPECIFICATIONS
Test Leads
Resistance
(OHMS)
Scale Reading
(x__________)
Between Brown Trigger Lead
and White/Black Trigger
Lead
1100-1400
11-14
(R x 100)
Between White Trigger Lead
and White/Black Trigger
Lead
1100-1400
11-14
(R x 100)
Between Violet Trigger Lead
and White/Black Trigger
Lead
1100-1400
11-14
(R x 100)
NOTE: Above readings are for a cold engine (room
temperature). Resistance will increase slightly, if en-
gine is warm.
4 CYLINDER TRIGGER SPECIFICATIONS
Test Leads
Resistance
(OHMS)
Scale Reading
(x__________)
Between Brown Trigger Lead
and Black Trigger Lead
700-1000
7-10
(R x 100)
Between White Trigger Lead
and Violet Trigger Lead
700-1000
7-10
(R x 100)
NOTE: Above readings are for a cold engine (room
temperature). Resistance will increase slightly, if en-
gine is warm.
3. If meter readings are not as specified, replace
trigger.
ADI Ignition using a RED
Stator with an Adapter
Module
Red stators require an adapter module that is con-
nected between the stator and switch box. Without
the adapter module, the voltage supplied by the sta-
tor would exceed the voltage capability of the switch
box.
To Next Page
