SECTION L
TIlE
UYDRAULI£
DAMPERS
L
Description.
Maintenance.
Section No.
L.r
Section
No.
L.2
Section
No.
L.3
Section
No.
LA
Section
No.
L.S
Section No. L.6
Section
No.
L.7
Section No.
L.S
R.eplen
ishIng.
R.emoval
and replacement of rear hydraulic dampers.
R.emoval
of front dampers.
Testing
the
hydraulic dampers.
R.eplacement
of rear- damper link bearings (Glrling).
To dismantle
the
links (Girling).
Fitting new bearings to lever arm and lever arm link (Girling).
Damper settings.
DESCRIPTION
The hydraulic dampers
are
double acting. resistance
being offered to
the
compression
and
to the recoil of
"the road springs. They
are
of either GJrling or
Armstrong manufacture.
MAINTENANCE
The maintenance of
the
hydraulic dampers. when in
position on
the
vehicle. is confined
to
pertcdtcal
replenishment and examination of
the
anchorage to
the
chassis.
the
fixing bolts being tlghtened as requi red.
The
renewal of
the
bearings requires
the
removal of
the
hydraulic dampers from
the
chassis. but replenish-
ment can be carried
out
with the dampers
either
in
position on
the
chassis
or
removed. No adjustment
of
the
hydraulic dampers is required
or
provided.
They are accurately
set
before
leaVing
the
Works
to
give
the
amount of damping most
SUitable
for the car.
Any
attempt
to
dismantle
the
piston
assembly
by
removing
the
caps
will
seriously
affect
the
operation
and
performance.
Seetlon
L.I
REPLENIS HI
NG
Every 12.000miles
or
2ססoo
kilometres
the
hydraulic
dampers should be topped up by removing
the
filler
plug and
filling up to
the
bottom of t.he filler plug hole
with
Girling
or
Armstrong
official
piston-type
hyd
raul
ic
damper
flu
ld,
according
to
the
dam
pen
fitted.
Before removing
the
filler
cap,
which is
located
on
the
to!=,
of
the
damper,
carefully
wipe
the
exterior,
as
it
is
of
utmost
irnpor-tance
that
no
dirt
whatever
enters
through
the
filler hole.
Fig.
L.I.
The location of the f lIer for the
front
hydrau IIcdampers
(Girllng type).
On no account neglect
the
operation of .. topping
up."
because Ifthe low-pressure chamber of
the
unit
isallowed
to
become empty. air will
enter
the
pressure
cylinders and
the
action of the damper will be impaired.
