4.4 Selection chart
(1) Equipment selection flow
Indoor unit
capacity (tentative) ≥
Indoor Load
Total indoor unit
capacity ≥ System Capacity
YES
YES
YES
NO
NO
NO
Select an indoor unit that matches the indoor load (tentative).
Calculate the total indoor unit capacity.
Indoor unit
capacity ≥ Indoor Load
Equipment selection complete.
Change the outdoor unit.
Calculate the temperature compensation,
then calculate the indoor unit capacity.
(See item (2) (a) for the calculation method.)
Calculate temperature compensation and piping
compensation, etc., then calculate the outdoor unit
capacity. (See item (2) (b) for the calculation method.)
Select the outdoor unit (tentative).
Calculate the system capacity
(See item (2) (c) for the calculation method.)
Calculate the indoor unit capacity.
(See item (2) (d) for the calculation method.)
Calculate the load for each room separately, then determine the indoor load.
Change the indoor unit.
