(e) Ceiling cassette-1 way compact type (FDTQ)
Item
kW
kW
W
CMM
Pa
kg
dB(A)
mm
Internal thermostat for fan motor.
Frost protection thermostat
Model
FDTQ22KXE6
2.2
TQ-PSA-15W-E QR-PNA-14W-ERTQ-PSB-15W-E QR-PNB-14W-ER
Direct blow panel Duct panel
(3)
2.5
1 Phase, 220-240V 50Hz/220V 60Hz
Electronic Expansion Valve
Direct line starting
Possible
Rubber sleeve(for fan motor)
Polyurethane foam
Flare piping
Connectable with VP20(I.D.20mm, O.D.26mm)
Necessary (both Liquid & Gas lines)
Mounting kit, Drain hose
Decorative Panel
Thermostat by electronics
Centrifugal fan 1
Liquid line: 6.35(1/4"), Gas line: 9.52(3/8")
mm(in)
Wired remote control switch (Optional:RC-E3)
Wireless kit (Optional:RCN-KIT3-E)
Louver fin & inner grooved tubing
20 1
Item
Indoor air temperature Outdoor air temperature
Standards
ISO-T1
Operation
DB WB DB WB
Cooling*
1
27
Heating*
2
20
19 35
7
24
6
Models FDTQ22KXE6
Unit:250 570 570
Panel:35
625 650
Unit:19
Panel:2.5
30
Unit:19
Panel:3
Unit:19
Panel:2.5
Unit:19
Panel:3
Unit:250 570 570
Panel:35
625 650
Unit:250 570 570
Panel:35
780 650
Unit:250 570 570
Panel:35
780 650
Nominal cooling capacity*
1
Panel model(Option)
Panel name
Nominal heating capacity*
2
Power source
Net weight
Starting method
Outside air intake
Air filter, Q'ty
Shock & vibration isolator
Insulation (noise & heat)
Room temperature control
Connecting method
Drain hose
Insulation for piping
Accessories
Optional parts
Motor
Air flow(Standard)
Available static pressure(at Hi)
Exterior dimensions
Height Width Depth
Refrigerant equipment
Heat exchanger
Operation control
Operation switch
Installation data
Refrigerant piping size
Noise level
Safety equipment
(1) The data are measured at the following conditions.Notes
(2) This packaged air-conditioner is manufactured and tested in conformity with the following standard.
ISO-T1 "UNITARY AIR-CONDITIONERS"
(3) This is the panel to be used when modified to the Duct panel type on site.
Refrigerant control
Air handling equipment
Fan type & Q'ty
Hi: 7 Lo: 5.4 Hi: 7 Lo: 6.5
Hi: 38 Lo: 33 Hi: 42 Lo: 39
Pocket plastic net 1(Washable)
Drain pump
Built-in Drain pump
