62
-
0.3mm
2
, 2 cores (O.D.ø5.6)
LCD display
120
Wall
Wire
(Recessed)
Electrical box
(Locally Purchased)
19
23
46
11.5
44
Remote controller
outline
120
45
83.5
42
120
Remote controller mounting dimensions
For the passage
after wiring
Attachment hole
12×7 Long hole
9×4.5 Long hole(4 pcs.)
48
Installation with wiring exposed Installation with wiring recessed
Cut off with a knife or the like
thin walled parts intended for
screw holes, and then fix it with
screws.
(2) Remote controller (Optional parts)
• Wired remote controller (Model: RC-E3)
Unit : mm
(This side is not grounded)
Earth wiring
Remote controller
Remote controller cord
(Shielded wire)
Precation in extending the remote controller cord
The cord should be a shielded wire.
● For all types : 0.3mm
2
2 cores
Note: (1) Use cables up to 0.5mm
2
(maximum) for those laid inside the remote controller casing and connect to a different size
cable at a vicinity point outside the remote controller, if necessary.
● The shielded wire should be grounded at one side only.
Maximum total extension 600m.
Within 100-200m
…………
Within 300m
…………
Within 400m
…………
Within 600m
…………
0.5 mm
2
0.75 mm
2
1.25 mm
2
2.0 mm
2
2 cores
2 cores
2 cores
2 cores
▼
Indoor unit
