384
-
5.3 EXCEPT FOR FDT & FDTC SERIES
This product is dedicated for heat pump unit. Never install on the unit dedicated for cooling.
(1) Wireless kit model
(2) Accessories (Confirm the following accessories).
(3) Wireless remote controller’s operable area
The receiver can be installed by replacing with a corner panel on the applicable decorative panel.
(a) When installed on ceiling
1 Standard reachable area of the signal
[Condition] Illuminance at the receiver : 300lux (when no lighting is installed within 1m of the receiver in an ordinary
office.)
1
1
1
1
1
1
1
2
3
1
2
3
4
1
2
3
2
3
4
5
6
7
2
2
1
5
5
1
2
2
2
1
1
1
Light detection
adaptor
Wiring (3m)
Parts set (A)
Parts set (B)
Parts set (C)
Wireless remote
controller
User’s manual
Screw for light
detetion adaptor
Remote controller
holder
Screw for holder
AAA dry
cellbattery (R03)
Fixing band
Clamp
Screw for clamp
Light detection section
installation bracket
Screw for the bracket
Installation fitting
Model
RCN-KIT3-E
Receiver
Orientation of receiver Ceiling surface
Floor
Floor
Receivable area
of the signal
Orientation of receiver Ceiling surface
Receivable area
of the signal
22˚
29˚
1.4m
2.4m
1m1.4m
2.4m
1m
2 Correlation between illuminance at the receiver and reachable area of the signal in a plain view.
[Condition] Correlation between the reachable area of the signal and illuminance at the receiver when the remote
controller is operated at 1.1m high under the condition of ceiling height of 2.5m.
When the illuminance becomes double, the area is narrowed down to two third.
(b) When installed on wall
[Condition] Illuminance at the receiver : 800lux.
The receivable area of the signal when
the illuminance at the receiver is 300lux.
The receivable area of the signal when
the illuminance at the receiver is 600lux.
Floor
0.6m
1.6m
Receiver
5m or less
Wireless
remote controller
5m or less
60˚ or less
30˚
or less
30˚
or less
To Next Page
