377
-
5.2 FDTC SERIES
The FDTC series is an exclusive series with all wired models. However, these models can also be used wireless units by using the
optional wireless kit.
(1) Wireless kit model
(2) Accessories
Please make sure that you have all of the following accessories.
(3) How to install the receiver
The receiver can be installed by replacing with a corner panel on the applicable decorative panel.
Preparation before installation
1 Attach the decorative panel onto the air conditioner according to the installation manual for the panel.
2 Remove the air return grille.
3 Remove a corner panel located on the refrigerant pipes side.
4 Remove to screws and detach the lid from the control box of the air conditioner.
Receiver
Parts set
Wireless
remote
controller
Remote controller holder
AAA dry cell battery
(RO3)
Wood screw for holder
Model
RCN-TC-24W-ER
Refrigerant pipesDrain pipe
Drain plug
To Next Page
