304
–
(c) Saving of Operation Data
Mainly for investigating causes of market claims, operation data are always saved in memory. If any trouble occurs, the
data writing is stopped and only the operation data prior to the time when the trouble occurs are recorded. These data can
be loaded to a PC via RS232C connector of PCB and utilized for identifying causes.
(i) Operation data for a period of 30minutes prior to the present operation are saved and updated continuously.
(ii) If an anomalous stop occurs, the data are not updated any more.
(ii) Data are written in based on 1 minute sampling interval and next data will be transmitted to PC upon demand.
Data Data range Example
Software version Ascii 15 bytes KD3C218######## (# : NULL)
PID (Program ID)
Ascii 2 bytes 5D
Outdoor unit capacity Ascii 3 bytes As listed blow
Power supply frequency
Ascii 2 bytes 60
Outdoor address Ascii 2 bytes 00 ~ 3F
Indoor address × 16 units Ascii 2 bytes × 16 units 40 ~ 7F
Indoor capacity × 16 units Ascii 3 bytes × 16 units 022 ~ 280
Outdoor unit composition Outdoor unit capacity data Remarks
Single type Example: 24HP - [S24]
S: Display with Horse Power of single type or
single use of combination type
Master unit of combination
type
Example: 46HP - [S46]
S: Display with Horse Power of master unit of
combination type
Slave unit of combination
type
Example: 20HP - [C20]
C: Display with Horse Power of slave unit of
combination type
(iv) Error retention and monitoring data
Code
No.
Write contents
Record data
Data write range Unit of write
Number of bytes
Contents
0 Indoor 1 ThI-A –14 ~ 50 A/D value 1 Suction
1 Indoor 1 ThI-R1 0 ~ 72 A/D value 1 Heat exchanger 1
2 Indoor 1 ThI-R2 0 ~ 72 A/D value 1 Heat exchanger 2
3 Indoor 1 ThI-R3 0 ~ 72 A/D value 1 Heat exchanger 3
4 Indoor 1 EEV 0 ~ 470 1 pulse 2
5 Indoor 1 operation/stop 0,1 – 1 0 Stop
1 Operation
6 Indoor 1 operation mode 0 ~ 4 – 1 0 Auto
1 Dehumidifying
2 Cooling
3 Fan
4 Heating
7 Indoor 1 request Hz 0 ~ 255 1Hz 1
8 Indoor 1 answer Hz 0 ~ 255 1Hz 1
9 Indoor 1 indoor local – – 1 Bit0 Anti-frost
Bit1 EEV opening angle
implementation
10 Indoor 1 Thi spare –14 ~ 50 A/D value 1 Discharge
11 Indoor 1 type 0 ~ 8 – 1 0 FDT
1 FDK
2 Others
3 FDE
4 FDTC
5
6
7
60 ~
12 Indoor 1PID – – 1
The data of indoor unit No.2-16 are continued. (contents are same as above)
