272
-
When plural remote controllers are connected, louver setting operation cannot be set by slave remote controller.
If it is necessary to fix the louver position manually, follow the procedure mentioned below.
1 Shut off the main power switch.
2 Unplug the connector of the louver motor which you want to fix the position. Make sure to insulate unplugged connec-
tors electrically with a vinyl tape.
3 Adjust the louver position slowly by hand so as to be within the applicable range mentioned below table.
Louver motor
Louver
Louver motor
Connector
43
Dimension L (mm)
26
It can be set between 26~43mm freely.
<Range of louver setting>
Vertical airflow direction Horizontal 0Ëš Downwards 45Ëš
Caution
• Any automatic control or operation from the remote controller will be disabled on the louver whose position is
fixed in the above way.
• Do not set a louver beyond the specified range. Failure to observe this instruction may result in dripping, dew
condensation, the fouling of the ceiling and the malfunctioning of the unit.
