(b) List of 7-segment displays
Code No. Contents of display Data display range Minimum unit Remarks
Error display [Exx]
Caution
display
[oPx]
Special display
[PdS][PdE][CHx][CHE]
[CHL][CHU][CHJ][CHO] and etc.
Code No. Contents of data display Data display range Minimum unit Remarks
<Sensor value, actuator information>
C00 CM1 operation frequency 0 ~ 130 1Hz
C01 (Spare) CM2 operation frequency 0 ~ 130 1Hz
C02 Tho-A Ambient air temperature L,-20 ~ 43 1Hz
C03 Tho-R1 Heat exchanger temperature 1 L,-25 ~ 73 1°C
C04 Tho-R2 Heat exchanger temperature 2 L,-25 ~ 73 1°C
C05 (Spare) Tho-R3 Heat exchanger temperature 3 L,-25 ~ 73 1°C
C06 (Spare) Tho-R4 Heat exchanger temperature 4 L,-25 ~ 73 1°C
C07 Tho-D1 Discharge pipe temperature (CM1) L,31 ~ 136 1°C
C08 (Spare) Tho-D2 Discharge pipe temperature (CM2) L,31 ~ 136 1°C
C09 (Spare)
C10 (Spare) Tho-C1 Under-dome temperature (CM1) L,5 ~ 90 1°C
C11 (Spare) Tho-C2 Under-dome temperature (CM2) L,5 ~ 90 1°C
C12 Tho-P1 Power transistor temperature (CM1) L,5 ~ 136 1°C
C13 (Spare) Tho-P2 Power transistor temperature (CM2) L,5 ~ 136 1°C
C14 Tho-SC Sub-cooling coil temperature 1 L,18 ~ 73 1°C
C15 Tho-H Sub-cooling coil temperature 2 L,-25 ~ 73 1°C
C16 Tho-S Suction pipe temperature L,-25 ~ 73 1°C
C17 (Spare) Temperature sensor (Active filter)
C18 CT1 (CM1) current 0 ~ 50 1A
C19 (Spare) CT2 (CM2) current 0 ~ 50 1A
C20 EEVH1 Heating expansion valve opening angle 0 ~ 500 1 pulse
C21
(Spare) EEVH2 Heating expansion valve opening
angle
0 ~ 500 1 pulse
C22
EEVSC Sub-cooling coil expansion valve opening
angle
0 ~ 500 1 pulse
C23 FMo1 Actual fan speed 0 ~ 999 10min-1
C24 (Spare) FMo2 Actual fan speed 0 ~ 999 10min-1
C25 PSH High pressure sensor 0 ~ 4.15 0.01MPa
C26 PSL Low pressure sensor 0 ~ 1.70 0.01MPa
C27 (Spare)
C28 (Spare)
C29 (Spare)
