Component Type Part Number Replacement Procedure
GTR 8000 Base Radio Backplane 0180706K30 Replacing a GTR 8000 Base Radio
Backplane
on page 245
Preselector 700 MHz 0185171Y02
Replacing a Preselector Filter on
page 250
Preselector 700/800 MHz 0185171Y01
Preselector Mounting Bracket 0785024Y01
Preselector QMA Cable End 3085664Y01
Preselector BNC to QMA Cable 3085665Y01
Preselector Mini UHF N-Bulkhead
Cable
3085664Y02
Preselector Mini UHF BNC Cable 3085664Y03
Preselector UHF 380–433 MHz CFX1075A
Preselector UHF 435–470 MHz TLE5992A
Preselector UHF 470–524 MHz TLE5993A
Preselector VHF 136–154 MHz TFD6511A
Preselector VHF 150–174 MHz TFD6512A
Transmit Post Filter 700 MHz 9184680Y01
Replacing Transmit Filters (700/800
MHz) on page 251
Transmit Post Filter 800 MHz 9184680Y02
External Dual Circulator Tray DLN1317A
Replacing the Dual Circulator/Isola-
tor Modules on page 253
External Dual Circulator Tray UHF
380–435
CLE6203A
Duplexer 700 MHz 9184718Y01 Replacing a Duplexer (700/800
MHz) on page 257
Duplexer 800 MHz 9184718Y02
Duplexer UHF 380–403 MHz 0185417U10
Replacing a Duplexer (UHF) on
page 259
Duplexer UHF 403–435 MHz 0185417U04
Duplexer UHF 435–470 MHz 0185417U05
Duplexer UHF 470–494 MHz 0185417U06
Duplexer UHF 494–512 MHz 0185417U07
Duplexer VHF 136–146 MHz 0185417U01
Replacing a Duplexer (VHF) on
page 261
Duplexer VHF 144–160 MHz 0185417U02
Duplexer VHF 158–174 MHz 0185417U03
Antenna Relay 40009272002
Replacing an Antenna Relay on
page 262
Antenna Relay and Circuit Load
Temperature Cable
3084848Y01
Antenna Relay Machine Screws (2) 0310909A54
External Speaker Kit HSN1006A
Microphone Kit GMMN4063B
MN003286A01-E
Chapter 9: GTR 8000 Base Radio FRU Procedures
224
