10.2.2

Preselector Filter Specifications (700/800 MHz)

Table 68: Preselector Filter Specifications (700/800 MHz)

Preselector Spec Limit

(700/800 MHz)

Typical

Frequency range 792–806 MHz

792–825 MHz

Insertion loss 1 dB 0.7 dB

VSWR max. 1.5:1 1.3:1

Tx selectivity 15 dB 18 dB

Input Connector QMA

Output Connector QMA

10.2.3

Preselector Filter Specifications (UHF)

Table 69: Preselector Filter Specifications (UHF)

Preselector Spec Limit

(UHF)

Typical

Tuning range 380–433 MHz,

435–470 MHz,

470–524 MHz

Bandwidth

4 MHz

Insertion loss 2 dB 1.3 dB

VSWR max. 1.9:1 1.5:1

Input Connector Mini-UHF

Output Connector Mini-UHF

10.2.4

Preselector Filter Specifications (VHF)

Table 70: Preselector Filter Specifications (VHF)

Preselector Spec Limit

(VHF)

Typical

Tuning range 136–154 MHz,

150–174 MHz

Bandwidth

4 MHz

Insertion loss 1.3 dB 1.1 dB

MN003286A01-E

Chapter

10: GTR 8000 Base Radio Reference

271
