FRU Kit Part Number
Description Quanti-
ty
5682347B20 BAG FOR SCREWS 1
CKN694
5A
CABLES, T1-2R W/TALKAROUND 1
3084921Y09 CBL, ASSY, COAX, 55CM, N-TO-QN 1
4285026Y01 CLIP, CABLE RETAINER 1
3013943E25 CBL N-BNC M-M 85CM 1
3084848Y01 CABLE RELAY W/TEMP 1
4210217A04 STRAP TIE .184X7.31 NYL BLK 10
5682347B21 BAG, PLASTIC 584 X 431 MM 1
SVCWARR12 12 MONTH STANDARD WARRANTY 1
A.2.2
Site Performance Expected for T1-2R with Talk-Around
The additional cables, splitter, and relay affect receiver sensitivity and transmitter output power. Use
the attenuation values found in this section to determine the expected site performance. Other base
radio and receiver specifications are not affected.
Table 84: Total Transmit and Receive Attenuation for T1-2R with Talk-Around
Band Type Attenuation CA01957AA: T1-2R
VHF Rx 1
0.6 dB typical
0.8 dB maximum
VHF Rx 2
0.9 dB typical
1.1 dB maximum
VHF Tx
0.8 dB typical
1.0 dB maximum
UHF Rx1
0.8 dB typical
1.0 dB maximum
UHF Rx2
1.3 dB typical
1.5 dB maximum
UHF Tx
1.2 dB typical
1.4 dB maximum
800 MHz Rx1
0.9 dB typical
1.1 dB maximum
800 MHz Rx2
1.7 dB typical
1.9 dB maximum
MN003286A01-E
Appendix A: Conventional
GTR 8000 Base Radio Option Kits
297
