NOTICE: When the GTR 8000 Base Radio or GPW 8000 Receiver is ordered with the
preselector option, the type N to BNC adaptor (58009291001) must be used on the
receiver end of RF cables.
See Figure 122: T4-4R Receiver Mute Configuration on page
286 for an example of how to route cables.
5 Replace the fan modules for the base radio and receivers. See Replacing the Fan Assembly on
page 237.
NOTICE: If you chose to turn off the power, set the rocker switch on the front of the
associated power supply to the On (I) position.
6 Place each device to Normal Mode, as follows:
a Connect to the transceiver module Ethernet service port using CSS. See Connecting
Through an Ethernet Port Link
on page 140.
b From the menu, select File → Read Configuration From Device.
c From the menu, select Service → Test And Measurement Screen.
d Click Change to Normal Mode.
e At the confirmation screen, click OK.
The device halts activity in the current mode and switches operation to the requested mode.
f Disconnect the Ethernet cable from the transceiver module Ethernet service port.
g Repeat for each device in the configuration.
A.1.7
Configuring the T2-2R, T3-3R, and T4-4R Receiver Mute Option Kits
Prerequisites: Ensure that all required installation procedures have been performed for the base radio
and receiver and that the devices have been powered up.
When and where to use: This procedure is used to configure the WildCard Tables for a Receiver
Mute configuration using the Configuration/Service Software (CSS).
Procedure:
1 If necessary, perform the initial configuration for the base radio and receiver. See Device
Configuration in CSS on page 134 for details.
2 Connect to the Ethernet port on the device. See Connecting Through an Ethernet Port Link on
page 140 for details.
3 From the menu, select File → Read Configuration From the Device.
4 From the navigation pane, select Hardware Configuration. Set Station Type [R] to Analog
Only.
NOTICE: When configuring GPW 8000 Receivers, the Hardware Platform [R]
parameter is set to GPW 8000 Satellite Receiver. The Antenna Relay [R] parameter is
not configurable for GPW 8000 Receivers.
5 Set Antenna Relay [R] to Enabled.
NOTICE: Use the default value of 30 ms for the Antenna Relay Delay. This step is not
required for GPW 8000 Receivers.
6 From the navigation pane, select WildCard Tables. Click Set to Default to add default
WildCard tables.
MN003286A01-E
Appendix
A: Conventional GTR 8000 Base Radio Option Kits
292
