A.3.1
T2-2R with Duplexer and Triple Relay Option Kit Parts List
The required hardware and cables for the CA01962AA T2-2R with a Duplexer and Triple Relay option
kit are listed in this section.
Table 85: T2-2R with Duplexer and Triple Relay Option Kit Parts List
FRU Kit Part Number
Description Quanti-
ty
DLN6800
A
T2-2R DUPLXR AND TRPL RELAY 1
CLN8793
A
HARDWARE, T2-2R DUPLXR AND
TRPL RELAY
1
0285854Y01 NUT, M6-GROUND WIRE TO STUDS
ON TRAY
2
0310909A54 SCREW 3.5X30MM ANT RELAY MTG 6
0310909E46 SCRMCH M3.5X0.6X8 ANT CONN &
SIDE BRKTS
20
0312016A49 SCREW FRONT PANEL TO CHASSIS
(blk)
4
0312016A54 SCRTPG M6 X 1 X 10 (blk) TRAY TO
RACK
4
07009370001 BRACKET CHASSIS SUPPORT 2
27009304001 CHASSIS, PERIPHERAL 1
40009272002 RELAY, COAXIAL 29V 3
5682347B20 BAG FOR SCREWS 1
64009317001 PANEL, FRONT 1
0285504U05 CAGE NUT, M6 FOR CABINET MTG 4
0310909C91 SCREW M6-GROUND CABLE TO BUS
BAR AND TRAY TO CABINET CAGE
NUTS
5
CKN694
6A
CABLES, T2-2R DUPLXR AND TRPL
RELAY
1
30009379001 CABLE, TRIPLE RELAY 1
3013942M11 CBL N-N M-M 32.5 CM 2
3013942M23 CBL N-N M-M 75 CM 1
3013942M29 CBL N-N M-M 110 CM 2
3013942P19 CBL N-N M-F PNL 55 CM 1
3013943E25 CBL N-BNC M-M 85 CM 1
3013943E27 CBL N-BNC M-M 95 CM 1
3084848Y01 CABLE RELAY W/TEMP 1
3071488H08 CABLE, GROUND TRAY TO BUS BAR 1
58009291001 Adapter, N Plug to BNC Jack 2
