• The power supply Fan LED is off.
•
Confirm proper operation using software tools, such as the UEM, and the Power Supply
Metering Screen in CSS.
9 Place the base radio in Normal Mode, as follows:
a From the menu, select Service → Test and Measurement Screen.
b Click Change to Normal Mode.
c At the confirmation screen, click OK.
The base radio halts activity in the current mode and switches operation to the requested
mode.
9.7
Replacing a Power Supply Fan
WARNING: The power supply module contains dangerous voltages which can cause electrical
shock to personnel or damage equipment.
NOTICE:
Replacing the power supply fan requires removing the power supply module. The power supply
output is directly mapped to a Power Amplifier (PA)/transceiver combination. Removal of a
power supply results in a loss of the associated channel until the replacement power supply is
inserted and turned ON.
Place a trunked device in Service Mode before replacing the module so that the system does
not attribute the loss of a channel to a failure. Placing the device in Service Mode is performed
using either the Unified Event Manager (UEM) or Configuration/Service Software (CSS).
