IC Approval
Number
Frequency Range Type Power Output
IC Model
Number
109AB-5829 Tx 851–869 MHz, Rx 806–824
MHz
C4FM, FM Variable 2-30W GTR8000-80
030W
109AB-5831 Tx 768–776 MHz, Rx 798–
806MHz
LSM Variable 2-30W GTR8000-70
030W
109AB-5831 Tx 768–776 MHz, Rx 798–
806MHz
C4FM, FM Variable 2-30W GTR8000-70
030W
1.12.2
GTR 8000 Base Radio Specifications for Integrated Voice and Data
UHF R1 (380–435 MHz)
Table 8: GTR 8000 Base Radio General Specifications for IV&D UHF R1 (380–435 MHz)
General Specifications
Model Number T7039A
Number of Channels (trunked) 1
Number of Channels (conventional) 16
Size (H x W x D) 133mm x 483mm x 457mm (5.25" x 19" x 18")
Weight 21 kg (46 lbs)
Temperature Range
Operating: -30 to 60 °C (-22 to 140 °F)
Storage: -40 to 85 °C (-40 to 185 °F)
Operating Altitude Up to 1800 meters (5900 ft) above mean sea
level
Above 1800 meters (5900 ft), the derating is 1.5
°C/km (0.8 °F/1000 ft)
Maximum operational altitude is 5000 meters
(16900 ft)
Power Requirements AC: 90-264 VAC, 47-63 Hz
DC: 43.2-60 VDC
Power Consumption (Transmitting)
AC: C4FM, FM: 500 W max.
H-DQPSK, LSM: 550 W max.
DC: C4FM, FM: 460 W max.
H-DQPSK, LSM: 510 W max.
Power Consumption (Standby)
AC: 110 W max.
DC: 75 W max.
Power Consumption (Standby with Power Effi-
ciency Package)
MN003286A01-E
Chapter
1: GTR 8000 Base Radio Description
45
