FRU Kit Part Number
Description Quanti-
ty
4210217A04 STRAP TIE .184X7.31 NYL BLK 10
5682347B21 BAG, PLASTIC 584 X 431 MM 1
SVCWARR12 12 MONTH STANDARD WARRANTY 1
A.3.2
Site Performance Expected for T2-2R with Duplexer and Triple Relay
The additional cables, and relays affect receiver sensitivity and transmitter output power. Use the
attenuation values found in this section to determine the expected site performance. Other base radio
and receiver specifications are not affected.
Table 86: Total Transmit and Receive Attenuation for T2-2R with Duplexer and Triple Relay
Band Type Attenuation CA01962AA: T2-2R
VHF Rx 1
1.0 dB typical
1.2 dB maximum
VHF Rx 2
1.2 dB typical
1.5 dB maximum
VHF Tx
1.4 dB typical
1.7 dB maximum
UHF Rx1
1.6 dB typical
1.8 dB maximum
UHF Rx2
1.9 dB typical
2.1 dB maximum
UHF Tx
2.0 dB typical
2.4 dB maximum
800 MHz Rx1
2.2 dB typical
2.5 dB maximum
800 MHz Rx2
2.6 dB typical
2.9 dB maximum
800 MHz Tx
2.9 dB typical
3.3 dB maximum
MN003286A01-E
Appendix A: Conventional
GTR 8000 Base Radio Option Kits
305
