Motorola ASTRO 25 GTR 8000 User Manual

Transmitter Specifications
Intermodulation Attenuation (High-Power, 800
MHz)
55 dB
Intermodulation Attenuation (Mid-Power,
700/800 MHz)
80 dB
*Full transmitter output power is available during battery revert.
NOTICE: The output power reference plane is the output connector of the power amplifier. The
loss of the transmitter output cable (PA output to back of base radio) is 4% at 800 MHz.
However, the base radio software allows the transmitter output power to be set at 10% above
rated value.
Table 5: GTR 8000 Base Radio Specifications for IV&D (700/800 MHz)
Receiver Specifications
Frequency Range 792–825 MHz
Modulation C4FM, H-CPM, FM
Analog Sensitivity (12 dB SINAD)
12.5 kHz: -118 dBm
25 kHz: -117 dBm
Digital Sensitivity 5% Bit Error Rate Static
(BER)
C4FM: -118 dBm
H-CPM: -116 dBm
Faded Sensitivity 5% Bit Error Rate (BER)
C4FM: -110 dBm
Intermodulation Rejection 85 dB
Digital Adjacent Channel Rejection 60 dB
Analog Adjacent Channel Rejection (EIA603)
Analog 12.5 kHz
75 dB
Analog Adjacent Channel Rejection (TIA603D)
Analog 12.5 kHz: 50 or 60 dB (adjustable)
Analog 25 kHz: 80 dB
Spurious and Image Response Rejection 85 dB
100 dB with preselector
Analog Audio Response +1, -3 dB from 6 dB per octave de-emphasis;
300–3000 Hz referenced to 1000 Hz at line out-
put
Analog Audio Distortion 3% or 5% (adjustable)
Analog FM Hum and Noise
12.5 kHz: 45 dB
25 kHz: 50 dB
MN003286A01-E
Chapter
1: GTR 8000 Base Radio Description
43
