General Specifications
Frequency Stability
External Reference
TRAK
Frequency Generation Synthesized
Table 19: GTR 8000 Base Radio Transmitter Specifications for IV&D VHF (136–174 MHz)
Transmitter Specifications
Frequency Range 136–174 MHz
Power Output* (Mid-Power) 2-100 W C4FM, FM
2-60 W LSM, H-DQPSK
Power Output* (High-Power) 2-100 W C4FM, FM
2-100 W LSM, H-DQPSK
Peak Envelope Power 2-100 W C4FM, FM
3.5-110 W LSM, H-DQPSK
Peak Envelope Power (High-Power) 2-100 W C4FM, FM
3.5-182 W LSM, H-DQPSK
Electronic Bandwidth Full Bandwidth
Modulation C4FM, LSM, H-DQPSK, FM
Modulation Fidelity 5%
Spurious and Harmonic Emissions Attenuation 90 dB
Analog FM Hum and Noise
12.5 kHz: 45 dB
25 kHz: 50 dB
Analog Audio Distortion Less than 2% (1% typical) at 1000 Hz
Emissions Designators 8K70D1W, 8K70D1E, 8K70D1D, 8K10F1W,
8K10F1E, 8K10F1D, 9K80D7W, 9K80D7E,
9K80D7D, 16K0F3E, 11K0F3E, 16K0F1D,
10K0F1D
Adjacent Channel Power Ratio
12.5 kHz offset, 6 kHz BW: 67 dB
Intermodulation Attenuation 55 dB
*Full transmitter output power is available during battery revert.
NOTICE: The output power reference plane is the output connector of the power amplifier. The
loss of the transmitter output cable (PA output to back of base radio) 1% at 150 MHz. However,
the base radio software allows the transmitter output power to be set at 10% above rated value.
If more than 70 dB Intermodulation Attenuation is required at a site, an external circulator
should be added to the transmitter output.
MN003286A01-E
Chapter
1: GTR 8000 Base Radio Description
54
