Configure Switching
133
Insight Managed 8-Port Gigabit Ethernet Smart Cloud Switch with 2 SFP Fiber Ports
View STP Statistics
You can view information about the number and type of bridge protocol data units (BPDUs)
transmitted and received on each port.
 To view Spanning Tree statistics:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is of
f-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser
, enter the IP address of the switch.
If you do not know the IP address of the switch, see Access the Switch on page 11.
The login window opens.
4. Enter the switch’
s password in the password field.
The default password is password. If you added the switch to a network on the Insight
app before and you did not yet change the password through the local browser interface,
enter your Insight network password.
The System Information page displays.
5. Select Switching > STP >
Advanced > STP Statistics.
The STP Statistics page displays.
6. T
o refresh the page with the latest information about the switch, click the Refresh button.
The following table describes the information available about the STP Statistics page.
Table 37. STP Statistics
Field Description
Interface The physical or port channel interfaces of the switch.
STP BPDUs Received The number of STP BPDUs received at the port.
STP BPDUs Transmitted The number of STP BPDUs transmitted from the port.
RSTP BPDUs Received The number of RSTP BPDUs received at the port.
RSTP BPDUs Transmitted The number of RSTP BPDUs transmitted from the port.
MSTP BPDUs Received The number of MSTP BPDUs received at the port.
MSTP BPDUs Transmitted The number of MSTP BPDUs transmitted from the port.
