NETGEAR GC110 User Manual

Manage Device Security
259
Insight Managed 8-Port Gigabit Ethernet Smart Cloud Switch with 2 SFP Fiber Ports
The following table describes the information that is displayed in the MAC Binding Table.
Table 64. MAC Binding Table
Field Description
Interface The interface of the ACL assigned.
Direction The selected packet filtering direction for the ACL.
ACL Type The type of ACL assigned to the selected interface and direction.
ACL ID The ACL name identifying the ACL assigned to the selected interface
and direction.
Sequence Number The sequence number signifying the order of the specified ACL relative
to other
ACLs assigned to the selected interface and direction.
Configure an IP ACL
An IP or IPv6 ACL consists of a set of rules that are matched sequentially against a packet.
When a packet meets the match criteria of a rule, the specified rule action (Permit or Deny) is
taken, and the additional rules are not checked for a match. You must specify the interfaces
to which an IP ACL applies, as well as whether it applies to inbound or outbound traffic.
Add an IP ACL
 To add an IP ACL:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is of
f-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser
, enter the IP address of the switch.
If you do not know the IP address of the switch, see Access the Switch on page 11.
The login window opens.
4. Enter the switch’
s password in the password field.
The default password is password. If you added the switch to a network on the Insight
app before and you did not yet change the password through the local browser interface,
enter your Insight network password.
The System Information page displays.
5. Select Security >
ACL > Advanced > IP ACL.
The IP ACL Configuration page displays.
The IP ACL page shows the current size of the ACL table compared to the maximum size
of the
ACL table. The current size is equal to the number of configured IPv4 and IPv6
ACLs plus the number of configured MAC ACLs. The maximum size is 100.
