NETGEAR GC110 User Manual

Monitor the System
332
Insight Managed 8-Port Gigabit Ethernet Smart Cloud Switch with 2 SFP Fiber Ports
View or Clear EAP Statistics
You can view information about Extensible Authentication Protocol (EAP) packets that are
received on a specific port.
 To view EAP statistics or clear the statistics:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired network connection, or connect directly to a switch that is
off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
Total Transmit Errors The sum of single, multiple, and excessive collisions.
Total Transmit Packets
Discarded
The sum of single collision frames discarded, multiple collision frames
discarded, and excessive frames discarded.
Single Collision Frames The number of successfully transmitted frames for which transmission was
inhibited by exactly one collision.
Multiple Collision Frames The number of successfully transmitted frames for which transmission was
inhibited by more than one collision.
Excessive Collision Frames The number of frames for which transmission failed because of excessive
collisions.
Dropped Transmit Frames The number of transmit frames discarded.
STP BPDUs Received The number of STP BPDUs received.
STP BPDUs Transmitted The number of STP BPDUs transmitted.
RSTP BPDUs Received The number of RSTP BPDUs received.
RSTP BPDUs Transmitted The number of RSTP BPDUs transmitted.
MSTP BPDUs Received The number of MSTP BPDUs received.
MSTP BPDUs Transmitted The number of MSTP BPDUs transmitted.
802.3x Pause Frames
Transmitted
The number of MAC control frames transmitted with an opcode indicating the
PAUSE operation. This counter does not increment when the interface is
operating in half-duplex mode.
EAPOL Frames Received The number of valid EAPoL frames of any type that were received.
EAPOL Frames Transmitted The number of EAPoL frames of any type that were transmitted.
Time Since Counters Last
Cleared
The elapsed time in days, hours, minutes, and seconds since the statistics were
cleared.
Table 74. Detailed port statistics (continued)
Field Description

NETGEAR GC110 Specifications

General

Switch type	Managed
Quality of Service (QoS) support	Yes
Console port	RJ-45
Power connector	DC-in jack
SFP module slots quantity	2
Installed SFP modules quantity	-
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
Product color	Gray
10G support	No
MAC address table	- entries
