Manage Device Security
284
Insight Managed 8-Port Gigabit Ethernet Smart Cloud Switch with 2 SFP Fiber Ports
a. Select the check box next to the interface.
b. Click the Delete button.
The binding is removed.
The following table describes the information displayed in the IP ACL Binding Table.
Table 67. IP ACL Binding Table
Field Description
Interface The interface.
Direction The selected packet filtering direction for the ACL.
ACL Type The type of ACL assigned to the selected interface and direction.
ACL ID/Name The ACL number (for an IP ACL) or ACL name (for a named IP ACL or
IPv6
ACL) identifying the ACL assigned to the selected interface and
direction.
Sequence Number The sequence number signifying the order of the specified ACL relative
to other
ACLs assigned to the selected interface and direction.
Configure VLAN ACL Bindings
You can associate an ACL with a VLAN. When an ACL is associated with a VLAN, it is
applied to all interfaces that are members of the VLAN.
 To configure VLAN ACL bindings:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is of
f-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser
, enter the IP address of the switch.
If you do not know the IP address of the switch, see Access the Switch on page 11.
The login window opens.
4. Enter the switch’
s password in the password field.
The default password is password. If you added the switch to a network on the Insight
app before and you did not yet change the password through the local browser interface,
enter your Insight network password.
The System Information page displays.
5. Select Security >
ACL> Advanced > VLAN Binding Configuration.
The VLAN Binding Configuration page displays.
6. In the VLAN ID field, enter the VLAN ID to which the binding must apply
.
To Next Page
