Configure Quality of Service
194
Insight Managed 8-Port Gigabit Ethernet Smart Cloud Switch with 2 SFP Fiber Ports
If you do not know the IP address of the switch, see Access the Switch on page 11.
The login window opens.
4. Enter the switch’
s password in the password field.
The default password is password. If you added the switch to a network on the Insight
app before and you did not yet change the password through the local browser interface,
enter your Insight network password.
The System Information page displays.
5. Select QoS > DiffServ >
Advanced > Service Configuration.
6. To display information for all ports and LAGs, click the All link.
7. Select one or more interfaces by taking one of the following actions:
• To configure a single interface, select the check box associated with the port, or type
the port number in the Go To Interface field and click the Go button.
• T
o configure multiple interfaces with the same settings, select the check box
associated with each interface.
• T
o configure all interfaces with the same settings, select the check box in the heading
row.
8. From the Policy Name menu, select a policy name.
9. Click the Apply button.
Your settings are saved.
The following table describes the nonconfigurable information displayed on the page.
Table 51. Service Interface Configuration information
Field Description
Direction Shows the traffic direction of this service interface (either In or Out).
Operational Status Shows the operational status of this service interface (either Up or Down).
Remove a DiffServ Policy From an Interface
 To remove a DiffServ policy from an interface:
1. Connect your computer to the same network as the switch.
