NETGEAR GC110 User Manual

Configure Quality of Service
196
Insight Managed 8-Port Gigabit Ethernet Smart Cloud Switch with 2 SFP Fiber Ports
5. Select QoS > DiffServ > Advanced > Service Statistics.
6. To refresh the page with the latest information about the switch, click the Refresh button.
The following table describes the information available on the Service Statistics page.
Table 52. DiffServ Service Statistics information
Field Description
Interface All valid port numbers on the switch with a DiffServ policy that is attached in the inbound
direction.
Direction The traffic direction of interface is inbound (In). This field shows only the direction for
which a Dif
fServ policy is attached.
Policy Name The name of the policy that is currently attached to the specified interface and direction.
Operational Status The operational status of the policy that is attached to the specified interface and
direction.
The value is either Up or Down.
Discarded Packets The total number of packets that are discarded for all class instances in this service policy
for any reason due to Dif
fServ treatment. This is the overall count per interface, per
direction. The discarded packets are supported in the inbound direction but not in the
outbound direction.
Member Classes All DiffServ classes that are defined as members of the selected policy name. Select a
member class name to display its statistics. If no class is associated with the selected
policy
, then the list is empty.

NETGEAR GC110 Specifications

General

Switch type	Managed
Quality of Service (QoS) support	Yes
Console port	RJ-45
Power connector	DC-in jack
SFP module slots quantity	2
Installed SFP modules quantity	-
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
Product color	Gray
10G support	No
MAC address table	- entries
