Polaris RANGER 1000 2020 Service Manual

2.52
9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
FINAL DRIVE MAINTENANCE
DRIVE SHAFT BOOT INSPECTION
Inspect the front and rear drive shaft boots
q
for
damage, tears, wear or leaking grease. If the boots
exhibit any of these symptoms, they should be replaced.
Check to see the boot clamps
w
are properly positioned.
WHEEL SERVICE
REMOVAL
1. Position the vehicle on a level surface.
2. Place the transmission in PARK and stop the engine.
3. Loosen the wheel nuts
q
.
4. Elevate the appropriate side of the vehicle by placing
a suitable stand under the frame.
CAUTION
Ensure the vehicle is properly supported and does not
tip or fall.
5. Remove the wheel nuts
q
and remove the wheel
w
.
INSTALLATION
1. Install the wheel
w
on the wheel hub
e
with the valve
stem toward the outside. Be sure rotation arrow on
the tire (if applicable) points toward the front of the
vehicle.
2. Attach the wheel nuts
q
and finger tighten them.
NOTICE
Do not lubricate the stud or the lug nut.
3. Carefully lower the vehicle to the ground.
4. Torque wheel nuts
q
and/or hub nut
r
to the proper
specification.
TORQUE
Wheel Lug Nuts (Steel):
60 ft-lbs (81 Nm)
Wheel Lug Nuts (Aluminum)
120 ft-lbs (163 Nm)
MAINTENANCE
