Polaris RANGER 1000 2020 Service Manual

11
9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
11.21
2. Install the four fasteners
q
securing the windshield to
the windshield plate. Do not torque.
3. Perform windshield adjustment. Refer to Tip-out
Windshield Adjustment page 11.21.
TIP-OUT WINDSHIELD ADJUSTMENT
1. Rotate the windshield level counter-clockwise to
release the windshield.
2. Loosen the four T40 Torx fasteners
q
securing the
windshield to the windshield plate.
NOTICE
Do not remove screws.
3. Align the windshield seal with the notch in the center
of the upper dash panel.
BODY / FRAME
