4. Install the four T20 Torx fasteners
q
to secure the
wiper motor trim panel to the windshield. Torque to
specification.
TORQUE
Windshield Wiper Motor Trim:
Torque until fully seated
TIP-OUT WINDSHIELD SERVICE
REMOVAL
1. Rotate the windshield lever on the dash to release the
windshield.
2. Remove the four fasteners
q
securing the windshield
to the windshield plate.
3. With the aid of an assistant, remove the windshield
from the vehicle.
INSTALLATION
1. With the aid of an assistant, install the windshield on
the vehicle.
BODY / FRAME
