2.64
9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
CHASSIS / ENGINE ELECTRICAL
GROUND
1. Remove the passenger seat base and storage bin to
access the chassis ground terminal
q
, located next
to the battery.
2. Inspect the engine ground terminal, attached to the
upper starter mounting bolt. The other end of the
engine ground cable is attached to the chassis
ground terminal.
3. Inspect the front vehicle ground
w
located under the
hood.
4. Remove and clean all ground terminals as necessary.
5. Ensure all chassis grounds are properly torqued.
TORQUE
Chassis Ground:
8 ft-lbs (11 Nm)
THROTTLE PEDAL INSPECTION
Inspect the throttle pedal
w
for free movement. Be sure
the throttle pedal returns normally when released. Refer
to PPS Test page procedure if experiencing a lack of
throttle response.
MAINTENANCE
