Polaris RANGER 1000 2020 Service Manual

11
9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
11.39
SIDE BEZEL SERVICE
REMOVAL
1. Remove the side bezel cover. Refer to Side Bezel
Cover Service page 11.38.
2. Remove the lower bolster fastener.
3. Remove the two upper bolster fasteners and remove
the bolster.
4. Remove the inside push rivet securing the side bezel
to the rocker panel.
5. Remove the two push rivets securing the side bezel
to the closeoff panel.
6. Carefully push the intake duct retainers in to release
from the side bezel.
7. Pivot the side bezel outward and lift up to remove
from the vehicle.
BODY / FRAME
