5.8
9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
FUEL SUPPLY LINE SERVICE
IMPORTANT
If vehicle was recently operated, allow it to cool down
for one hour to allow fuel pressure to drop down before
attempting to perform any work.
REMOVAL
1. Place a shop towel around the fuel line to catch any
dripping fuel.
2. To remove the fuel line from the tank
q
or the fuel rail
w
, pull open tabs while moving the connector out to
release the line. Refer to Fuel Line Quick Connect
Removal page 5.6
3. Disconnect the retention clips retaining the fuel line to
the inner clutch cover and engine breather hose.
Remove the fuel line.
CAUTION
Use care not to damage the fuel line on nearby parts.
FUEL SYSTEM
