GENERAL INFORMATION - TRANSMISSION
SERVICE NOTES - TRANSMISSION
WARNING
Serious injury may result if machine tips or falls. Be
sure machine is secure before beginning any procedure
that requires machine lifting. Always wear eye
protection.
The transmission has two traction operational modes:
Differential Lock and Differential Unlock. Locking the rear
differential is beneficial in low traction and rough terrain
conditions. Unlocking the rear differential makes
maneuvering easier and minimizes damage to terrain.
SPECIAL TOOLS - TRANSMISSION
PART
NUMBER
TOOL DESCRIPTION
PU-52547 Snorkel Tube Tool
2871699 Rear Driveshaft Seal Guide
2871698
Rear Output Seal Driver
2871282
Bearing Seal Driver (50 mm)
Bosch Automotive Service Solutions: 1-800-345-2233
or http://polaris.service-solutions.com
TRANSMISSION SPECIFICATIONS
PART DESCRIPTION
VALUE
Transmission Type
Polaris Automatic PVT
Shift Type
In Line Shift - H / L / N /
R / P
Gear Reduction - Low
Front: 8.56:1
Rear: 25.59:1
Gear Reduction - Reverse
Front: 7.67:1
Rear: 22.92:1
Gear Reduction - High
Front: 4.03:1
Rear: 12.05:1
Fluid Type
AGL Gearcase
Lubricant &
Transmission Fluid
Fluid Capacity
41 oz (1200 mL)
TRANSMISSION
To Next Page
