Polaris RANGER 1000 2020 Service Manual

11.32
9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
4. Torque all fasteners to specification.
TORQUE
Front Bumper Fasteners
30 ft-lbs (41 Nm)
FRONT FENDER SERVICE
UPPER FENDER REMOVAL
1. Remove the hood by turning each 1/4 turn fastener
90 degrees to unlock the hood. Lift the hood straight
up and out.
2. Remove the three push rivets
q
and the T-30 torx
fastener
w
.
3. Remove the two push rivets
e
behind the front
fascia.
4. Pull upper fender straight out as shown.
BODY / FRAME
