10.18
9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
FRONT CALIPER REMOVAL
1. Elevate and safely support the front of the vehicle.
2. Remove the four wheel nuts and the front wheel.
CAUTION
Use care when supporting vehicle so that it does not tip
or fall. Severe injury may occur.
3. Clean caliper area before removal.
4. Place a container below the caliper to catch brake
fluid when removing line. Remove brake line
q
from
caliper.
5. Loosen brake pad adjustment set screw
w
to allow
brake pad removal after the caliper is removed.
6. Remove the two caliper mounting bolts and caliper
e
.
BRAKE SYSTEM
