Polaris RANGER 1000 2020 Service Manual

11
9850045 R01 - 2020-2021 RANGER 1000 Service Manual
© Copyright Polaris Inc.
11.53
DOOR LATCH SERVICE
REMOVAL
1. Remove the door panel.
2. Remove the four fasteners
q
securing the door latch
w
and remove the door latch.
INSTALLATION
1. Install the door latch
w
and four fasteners
q
to
secure the latch. Torque to specification.
TORQUE
Door Latch Fasteners
8 ft-lbs (11 Nm)
2. Install the door panel.
WINDOW REGULATOR / DOOR GLASS
SERVICE
REMOVAL
1. Remove the door panels.
2. Remove the three window motor fasteners
q
and
window regulator fastener
w
.
3. Disconnect the speaker and window harness from the
regulator support.
4. Remove the five fasteners
e
securing the upper
regulator support bracket, and remove the bracket.
BODY / FRAME
