5. Tighten the Press Asm. screw and fully remove the
ball joint from the A-arm.
BALL JOINT INSTALLATION
1. By hand, install the NEW ball joint into the A-arm.
2. Position the Installation Adapter
w
over the face of
the ball joint.
NOTICE
Image for reference only.
3. Position the Spacer
q
over the shaft of the ball joint
so it is against the A-arm.
4. Install the Press Asm.
e
onto the A-arm to engage
the Installation Adapter and Spacer.
5. Tighten the Press Asm. screw and fully install the
ball joint into the arm.
