GENERAL INFORMATION - PVT SYSTEM
PVT SPECIFICATIONS
PART DESCRIPTION SERVICE SPECIFICATION SERVICE LIMIT
Drive Clutch Spring Free Length
7044938: 3.76 in (95.43 mm) —
7045195: 2.73 in (69.34 mm) —
Drive Clutch Button to Tower Clearance 000-.010”
0.020” (0.508 mm)
Drive Clutch Shaft Diameter
1.57 in (39.98 mm) —
Vespel® Thrust Washer Thickness 0.030 - 0.040” (0.762 - 0.962 mm) 0.029” (0.742 mm)
Driven Clutch Spring Free Length 4.52 in (114.72 mm) —
CLUTCH SETTINGS
THREE SEAT / CREW
CLUTCHES
ALTITUDE
SHIFT WEIGHT (PN) DRIVE SPRING (PN) DRIVEN SPRING (PN)
0-1800 Meters
(0-6000 Feet)
32-112 HC
(1323704)
Black
(7045195)
Black
(7044761)
1800-3700 Meters
(6000 - 12000 Feet)
32–102 HC
(1323713)
Black
(7045195)
Black
(7044761)
