Chapter 12 Installing, Removing, and Replacing
Cable Management Guidelines
Scalar i500 User’s Guide 327
Figure 51 shows how a 41U library with FC I/O blades installed would
appear with power, Ethernet, and fibre cables installed and managed
according to these guidelines.
Figure 51 Cable Management,
All Cables, FC I/O Blades
Installed
