Chapter 1 Description
Back Panel Components
Scalar i500 User’s Guide 20
the access door of the control module. The library operations and service
functions are performed from this screen. The GUI is also accessible
through a remote Web client. For more information on the library user
interfaces, see Chapter 2,
Understanding the User Interface.
Front Power Button 1
Turning off the front power button turns off the robot and operator panel,
but power still runs to the power supplies. Use the front power button to
manually shut down the library. See Shutting Down, Powering Off, and
Completely Removing Power on page 242 for instructions on how to shut
down or restart the library safely.
Back Panel Components
Figure 6 shows the back panel components of the library. The paragraphs
following Figure 6
describe the components in detail.
